- Weight
13.5Kg
- Brakes
Hydraulic Disc
- Suspension
Full
- Frame
Aluminum
Build
- Frame
ALUXX-grade aluminum, 125mm FlexPoint suspension, 12x148mm thru-axle
- Fork
Crest 34 SL RCL, 140mm, Boost 15x110 QR, custom tuned for Giant
- Bottom Bracket
SRAM PowerSpline, threaded
- Handlebar
Giant Contact SL TR35, 780x35mm
- Stem
Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
- Saddle
Giant Romero
- Grips
Giant Sole-O
- Seatpost
Giant Contact Switch AT dropper, remote S: 140mm - 110mm travel / 30.9 x 395mm M: 170mm - 140mm travel / 30.9 x 470mm L: 200mm - 170mm travel / 30.9 x 530mm XL: 200mm - 170mm travel / 30.9 x 530mm
Prices
- 🇨🇦 $2899
- 🇬🇧 £2399
Groupset
- Rear Derailleur
SRAM SX Eagle
- Crank
SRAM SX Eagle PowerSpline, 30t S:165mm, M:170mm, L:170mm, XL:170mm
- Shifters
SRAM SX Eagle, 1x12
- Chain
SRAM SX Eagle
- Brakes
Shimano BR-MT420, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm
- Cassette
SRAM SX Eagle, 11x50
Wheels
- Tyres
[F] Maxxis Minion DHF 29x2.5 WT, EXO, TR [R] Maxxis Dissector 29x2.4 WT, Dual, EXO, TR, tubeless
- Rims
Giant AM 29 alloy, tubeless ready
- Front Hub
[F] Giant Tracker Performance Boost 15x110, sealed bearing [R] Giant Tracker Giant Sport QR141, loose ball
- Rear Hub
[F] Giant Tracker Performance Boost 15x110, sealed bearing [R] Giant Tracker Giant Sport QR141, loose ball
Geometry
| Sizes | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack (MM) | 614 |
623 |
632 |
636 |
| Reach (MM) | 415 |
445 |
470 |
500 |
| Top Tube Length (MM) | 563 |
595 |
622 |
654 |
| Seat Tube Length (MM) | 400 |
425 |
450 |
475 |
| Seat Tube Angle | 76.5 |
76.5 |
76.5 |
76.5 |
| Head Tube Length (MM) | 100 |
110 |
120 |
125 |
| Head Tube Angle | 65.5 |
65.5 |
65.5 |
65.5 |
| Chainstay Length (MM) | 440 |
440 |
440 |
440 |
| Bottom Bracket Drop (MM) | 40 |
40 |
40 |
40 |
| Bottom Bracket Height (MM) |
|
|
|
|
| Stack Reach Ratio | 1.48 |
1.4 |
1.345 |
1.272 |
| Rake (MM) | 45 |
45 |
45 |
46 |
| Trail (MM) | 121 |
121 |
121 |
120 |
| Front Center (MM) | 727 |
761 |
790 |
823 |
Sizing
| Sizes | SM | MD | LG | XL |
|---|---|---|---|---|
| Min Rider Height (CM) | 163 |
170 |
178 |
186 |
| Max Rider Height (CM) | 173 |
181 |
189 |
198 |
These values are not exact, the values are estimated using the bike's geometry or other data
Data provided by 99Spokes
