Canyon has just launched its brand new 2019 Lux full suspension race bike. Wil went over to Girona in Spain to test it out.
Show More Show Less View Video Transcript
0:00
everyone it's will hear from single
0:02
track magazine and single track WorldCom
0:04
and I'm here to talk to you about the
0:06
2019 Canyon lux now a few weeks girls
0:10
invited out to Girona in Spain to test
0:13
out the new Lux
0:14
this is canyons new lightweight full
0:16
suspension XC race bike now it replaces
0:18
the existing Lux in the Canyon liner a
0:21
bike which is coming up to five years
0:23
old this year the new lux carries over
0:25
the 29 inch wheels one hundred mil
0:26
travel front and rear it's still
0:28
designed to be a very sharp lightweight
0:30
and efficient cross-country race bike
0:32
but almost everything has changed it's
0:34
entirely new from the ground up the luxe
0:37
frame will only be available in
0:38
carbon-fiber there are no alloy versions
0:40
available at all but there are two
0:42
versions of the carbon-fiber frame just
0:45
like other Canyon models you've got an
0:47
SL frame an SL X frame
0:49
now the SL X uses a slightly lighter
0:52
weight carbon fiber and as a result the
0:55
whole frame is a little bit lighter
0:56
you're talking sixteen hundred and
0:59
sixty-two grams is the claimed weight
1:01
for a medium luxe SL X frame however
1:03
that weight is for the bare frame once
1:07
you add in the rear shock the remote
1:08
lockout the chain guide through axle
1:11
seek collar and a few other bits of
1:13
hardware you're looking at 21 28 grams
1:16
which is not quite as headline-grabbing
1:19
as the original figure but still very
1:21
impressive nonetheless there are some
1:23
really nice features on the luxe frame
1:25
some of which have carried over from
1:27
other Kenyan models and some which are
1:29
brand new we've got the impact
1:31
protection unit up at the headset and
1:33
the IPU basically stops the headset from
1:35
over rotating so in the event of a crash
1:38
your handlebars are limited how far they
1:41
can turn around and therefore hopefully
1:43
stop the shifter and brake lever from
1:45
careering through the top tube which is
1:47
quite nice we've also got the qixels
1:50
rear axle on the back so this is boost
1:53
spacing on the back and we've got a
1:54
really neat little integrated axle which
1:57
just pulls out of the back end and
1:59
allows you to loosen or tighten the rear
2:01
axle without any tools which is quite
2:03
neat another neat feature on the new
2:06
luxe is the super minimalist chain guide
2:09
I think this weighs about four point two
2:11
grams or something like that it's just a
2:13
little light
2:13
alloy guide that bolts into the head of
2:15
the main pivot bolt it can be adjusted
2:18
for different chain ring sizes very
2:20
simple very minimalist but does the job
2:23
really well the main difference with the
2:25
new luxe frame is of course the layout
2:28
with suspension now Kenyon have flipped
2:30
the rear shock from a vertically mounted
2:32
shock up to the top tube and the idea
2:36
here
2:37
aside from performance advantages that
2:39
it's provided it also delivers a lot
2:42
more space inside the main frame so now
2:44
for every single frame size you can fit
2:46
two full-sized water bottles inside the
2:49
main frame that goes for the small
2:51
medium large and extra-large frame sizes
2:53
for long distance riders and marathon
2:55
races this is a really big deal because
2:57
it means they can carry two water
2:59
bottles on the frame for racing you're
3:01
all less likely to need to stop at a
3:03
feed zone in order to refill a bottle
3:05
grab a fresh one you can just go
3:07
straight on through the suspension
3:08
design itself has changed considerably
3:10
we still have a carbon-fiber one-piece
3:13
wing arm so there's no pivots at the
3:15
back the swing arm is designed to flex
3:17
through the carbon seat stays as the
3:19
suspension cycles through its travel
3:20
there's two little links that drive the
3:23
rear shock we've got a carbon fiber yoke
3:25
which attaches to the lower eyelid of
3:27
the rear shock and a little alloy link
3:29
on the inside which bolted to the seat
3:31
tube and controls the link as it goes
3:33
through the travel the rear shock itself
3:37
is a metric size we've got a 210 by 55
3:39
mils stroke now that is quite a big
3:41
shock especially for a short travel
3:44
cross-country race bike with 55 mils
3:46
stroke and a hundred mil travel we end
3:49
up with an average suspension leverage
3:51
ratio of 1.8 1 to 1 so very low and that
3:55
means we end up with quite low operating
3:57
pressures for my 70 kilo right away I
3:59
had 110 psi in the rear shock to get me
4:02
at 25% sag so quite low pressures
4:05
relative to other cross-country race
4:07
bikes the bike that I was riding at
4:09
launch is the second from the top it is
4:12
cold wait for it the luxe CF s LX 9.0
4:16
pro race just rolls off the tongue that
4:19
one it's a sub 10 kilogram carbon fibre
4:23
race with it super light super trick
4:26
we've got a SRAM X
4:27
one Eagle group said on here we've got a
4:29
rock shock suspension package with a
4:31
Sidwell cut fork on the front very
4:34
lightweight Reynolds wheels these are
4:36
carbon-fiber rims and they weigh less
4:38
than 1400 grams for the passive very
4:40
light thankfully a dropper post which
4:43
was a very nice addition for the trails
4:45
that we were riding so the writing
4:47
position on the lux
4:48
it is fairly traditional for a
4:50
cross-country bike the basic numbers for
4:52
geometry we've got a 70 degree head
4:54
angle and a 74 point five degree seat
4:56
angle so quite sharp the reach on the
4:59
medium size that I was riding is 435
5:02
millimeters that combined with an 80 ml
5:05
stem 720 millimeter bars it does put
5:08
quite a lot of weight on the front wheel
5:10
stretches you out over the cockpit puts
5:12
you in a really good position for
5:14
climbing and getting the power down on
5:15
the pedals and in general this bike it
5:18
does pedal very very well very efficient
5:21
I found it quite an exhausting bike to
5:23
ride because it encourages you to get
5:25
out of the saddle and hammer it really
5:28
goes you into going faster and just put
5:30
more effort in it's not a bike that's
5:32
really interested in going slowly it
5:33
wants you to go fast so at the end of
5:37
end of the day I was absolutely
5:39
knackered riding this bike the
5:41
suspension design is really efficient
5:42
and to be honest I don't know why
5:44
canyons bothered with the remote lock
5:45
out on the handlebar the dual lockout
5:48
activates both the fork and the shock
5:50
but to be honest this bike doesn't need
5:52
it it pedals really really well as is if
5:55
it was my bike I'd be taking that off
5:57
straight away personally although the
5:59
suspension is very very stable and very
6:01
balanced under pedaling it's also still
6:05
active so great traction levels on this
6:08
bike
6:09
it actually has quite good big hit
6:10
capability so I took it off some
6:12
reasonable sized drops and jumps and the
6:15
bike stayed really planted without sort
6:17
of squirreling about yeah in general the
6:20
suspension gives the whole bike a lot of
6:22
stability and a lot of calmness so even
6:25
though those geometry numbers are quite
6:26
sharp quality of the rear suspension
6:28
gives this bike a load more capability
6:30
and a load more stability than perhaps
6:32
those geometry numbers would suggest the
6:34
fork didn't quite match the quality of
6:36
the rear suspension turns out there
6:38
weren't any bottomless tokens inside the
6:40
air spring
6:41
of the CID Forks that we are writing and
6:42
that's something I would do if I had a
6:44
bit more time with this bike is to put a
6:45
couple of tokens inside there to give it
6:47
a bit more progression and a bit more
6:48
ramp up to balance with the rear
6:50
suspension but otherwise I really
6:54
enjoyed riding this bike and it
6:55
surprised me quite a lot with how well
6:57
it rode on quite rough rocky terrain
6:59
that we were riding around Girona
7:01
now for the 2019 Canyon luxe range there
7:04
will be six models available the two
7:06
top-end models will use the lighter
7:08
weight SLX frame and the four cheaper
7:10
models will use the SL frame the SL
7:13
models will also come with a longer
7:15
travel fork 110 millimeters of travel
7:17
that will kick back the angles a little
7:19
bit and in theory should relax a
7:21
steering a little bit especially for
7:22
descending of note is that any model
7:25
that comes with the RockShox fork has a
7:27
longer 51 mil fork offset whereas the
7:30
Fox models will come with a shorter 44
7:33
mil off set now that will give a
7:35
slightly different steering dynamic so
7:37
with the Fox fork models you are going
7:39
to get a slightly Karma and more damped
7:41
steering feel whereas the RockShox
7:44
models you're going to get that sharper
7:45
more responsive feel that you get with a
7:47
longer offset so that's something to
7:49
bear in mind as well now if you'd like
7:52
to read more about the 2019 Canyon luxe
7:55
Range make sure you jump on singletrack
7:57
worldcom you'll be able to read our full
7:59
news story on the new bike as well as my
8:01
first ride review of this very
8:03
lightweight very efficient and very
8:06
stealthy full suspension race bike from
8:08
Kenyon thanks guys to route
