Alex from SRAM talks us through the new 'AXS' integrated wireless electronic system. It's not just a derailleur with the cables taken off - find out more about the development of this top end technology here.
Full story here: https://singletrackworld.com/2019/02/sram-axs-ditch-the-cables-and-go-wireless/
Show More Show Less View Video Transcript
0:00
the first thing you notice is whoa it's
0:03
an entirely different system just o
0:06
Voodoo or something it stands alone in
0:08
terms of technology and performance you
0:10
know there's nothing out there right now
0:11
that that is
0:17
comparable hi I'm Hannah from single
0:19
track and I'm here with Alex from Shram
0:22
to talk about the new axis range of
0:25
products which are being launched today
0:28
so axis is a
0:30
XS isn't it you see it written down um
0:34
and so what is it what's in the axis
0:37
range it's a good question so uh yeah
0:40
access Shram access and rock shock
0:42
access is our new wireless electronic
0:45
components for for the mountain bike so
0:47
you might have seen you know for for a
0:50
few years actually we've had red EAP
0:52
which has been our electronic Road
0:53
system you know fully Wireless so we're
0:55
now introducing that finally to to the
0:57
mountain bike so in terms of what we've
1:00
got here you have Eagle access and
1:03
Reverb access and they are our main two
1:06
two product groups of the MTB side um so
1:08
Eagle access building on what people are
1:11
familiar with now Isam Eagle drivetrain
1:14
um one by drivetrain system but truly
1:16
putting a fully Wireless integrated
1:18
system with a controller and a derailer
1:20
no kind of connected cables or all that
1:22
kind of good stuff so yeah there's
1:24
nothing between here and over there is
1:27
there it's just just o Voodoo or
1:29
something that go most mostly yeah so
1:33
you're right there's no you know there's
1:34
no cables there's no kind of wrapping
1:36
there's nothing going through the bike
1:37
or anything it is purely a a derailer
1:40
system and a controller up here and they
1:42
communicate with each other via
1:43
Bluetooth and plus EAP signals three
1:46
combinations and you know access in
1:48
itself is the the name the the umbrella
1:51
that all of these products live under in
1:53
terms of how they communicate with each
1:55
other from electronic product and uh
1:57
software integration so you can you know
2:00
get them to to do what they need to do
2:02
uh and Reverb as well Falls underneath
2:04
that so you know Reverb access you have
2:06
a controller on this side of the bike
2:08
and the Reverb itself so again no no
2:10
hoses no cables no wires it literally
2:12
just communicates from that controller
2:14
with this uh you know motor gearbox and
2:18
Battery system up here to control Reverb
2:20
electronically okay so it's quite nice
2:23
to imagine all the other things that
2:24
might might appear in the future which
2:26
you're definitely not going to tell me
2:27
about the aim here with Wireless
2:31
shifting and wireless Reverb is
2:34
basically to to build a better bike is
2:36
to build a system that is more um you
2:39
know it's more intuitive it's easier to
2:40
use it's more user friendly you stick it
2:42
on the bike and you and you get the
2:45
perfect shift every time don't you well
2:46
that's the aim of it yeah you know like
2:49
shifting shifting a mechanical part on a
2:52
bike a mechanical drivetrain isn't
2:54
overly difficult and it doesn't take a
2:55
huge amount of force but it does require
2:57
human input You' got to pull a cable the
2:59
right amount you got to throw the lever
3:00
just enough that it changes up on a Gear
3:02
you do it kind of at the right time with
3:03
the right sort of pace in your legs now
3:05
we all do that as mountain bikers and
3:06
it's not not trying to pretend it's
3:08
rocket science here and we've you know
3:10
built an arc to sail everyone away on
3:11
it's very much like it's just it's an
3:13
improved system it's the next level of
3:16
what bicycle components can be to make a
3:20
a better bike ultimately so so so really
3:22
this going to appeal to the racers isn't
3:24
it because they're going to they're
3:25
going to be able to focus on racing and
3:27
getting the perfect shift every time
3:29
taking the perfect line and they're not
3:31
having to spend any time thinking about
3:33
how much their thumb is moving but
3:36
there's going to be a whole bunch of
3:36
people who are going to want the best
3:40
best technology that a bike can have and
3:41
that they will be the ones that will
3:43
also buy this is it for just a type of
3:45
person yes we've been racing this Nino
3:48
sh has been racing this for nearly a
3:50
year now and he won the World Cup on it
3:51
he's won the world Champs on it this
3:53
year again you know which is which is
3:55
phenomenal but is it just for races so
3:57
no it's for it's for everyone that
3:59
really wants to the best possible bike
4:01
you can build and in terms of bike
4:03
building and bike design because you
4:05
haven't got any cables in there there's
4:07
some potential for for kind of
4:09
interesting new bike builds as well new
4:12
frame builds potentially isn't there cuz
4:14
you haven't got to get a cable line
4:16
through the suspension through the swing
4:18
arm but yeah you're right getting a
4:21
getting a a shifter cable through a
4:23
frame or along side of a frame and into
4:24
the rear triangle of a bike and through
4:26
this part can have or does have an
4:28
impact on how you build a bike and where
4:31
that cable goes and actually does have
4:32
an impact as well on the suspension
4:34
performance of the bike if you take away
4:35
that complexity and need to rout a cable
4:37
and go through here and go around there
4:39
and you had two components to the bike
4:41
that ultimately deliver that function of
4:44
you know Flawless shifting um but
4:47
without having the added complexity yeah
4:48
it make it's a it's a it's another step
4:50
forward I think in what bikes are one by
4:53
really open that envelope this and
4:55
created better bikes this again is is
4:57
another step in that direction in terms
5:00
of the the of the functionality of of
5:03
this with the app I believe you can
5:06
alter um what a button does in terms of
5:09
like whether you get one one step or
5:12
three steps and that kind of thing is
5:13
that right now I guess it's the first
5:15
key thing it's got to be worth saying is
5:17
actually you can you can run access on a
5:19
bike and just bolt it on press a button
5:21
there press a button there link them
5:23
together and they are communicating with
5:24
each other um via ant plus um EAP and
5:28
Bluetooth and it's a secure kind of it's
5:30
a secure communication and it's just
5:32
going to work you know you don't need to
5:34
pull out an app if you don't want um but
5:36
if you choose to and you want to get
5:38
involved in that you're absolutely right
5:39
you've we've got two component groups
5:42
here we've got Drive training we've got
5:43
a seat post and as you mentioned Hannah
5:45
there's there's three buttons you've got
5:46
inboard shift outboard shift and the
5:48
Reverb itself so think of it as just
5:50
three buttons and you can assign those
5:52
three buttons to do whichever one you
5:55
want to do right so as it comes from the
5:58
factory and how we would Speck it you
6:00
know you would have both your shifting
6:02
done on your derailer controller like up
6:05
and down shifting and then your Reverb
6:07
control done on your reever controller
6:10
but you if you wanted this for example
6:12
button if this button you wanted to be
6:14
your inboard shift and this button then
6:17
on this side to be your outboard shift
6:18
that's totally fine and then you could
6:19
assign the top button on there to be
6:22
your dropper post yeah yeah and you can
6:24
also as you mentioned you can change how
6:26
many gears it shifts if I'm just
6:28
pedaling along and you press and hold
6:30
one of the buttons on the derailer
6:32
that'll shift the derailer all the way
6:34
along yeah or you could just have it
6:35
shift two gears or three gears again
6:37
like it's totally up to you you can
6:39
change settings on there for sure cool
6:41
and then there are two clutches in here
6:44
yes the derailer itself is you know
6:46
inside of this derailer we've got you
6:48
you got the battery you can see at the
6:49
back here so it's all self-contained
6:51
there's a motor and there's a gearbox
6:52
it's going to actuate that movement in
6:54
order to protect it though we need to
6:57
make sure that it's going to be durable
6:59
enough for mountain bike and so it's got
7:00
to it's going to take some knocks and
7:02
tumbles it's going to be you know it's
7:03
going to work on the more stressful
7:05
situations covered in mud and and all
7:07
the rest of it and getting a few wax off
7:08
rocks so there's two types of clutches
7:11
in there that are going to protect it
7:12
one or one clutch that we're all should
7:14
be familiar with which is your your
7:16
derailer clutch which um keeps our our
7:19
chain retention so type three roller
7:21
bearing clutch and then the second type
7:23
of clutch you got in there is what we
7:24
call the overload clutch now that is a
7:26
clutch that when this derail or if this
7:30
derer was to take a knock and some a big
7:32
old rock was going to come in from the
7:33
side and strike it you know what the
7:35
last thing we want is that derailer to
7:37
burst into pieces or to to bend your der
7:39
raail hanger over or to not be
7:40
functioning properly so we've built in
7:41
an electronic clutch system where if
7:44
you're going to give that a knock it's
7:45
going to move over on a clutch and then
7:46
it's going to come back into its
7:47
original position
7:51
again so it's a little bit of you've got
7:53
to build in a bit of protection there
7:54
from M Bing the other thing that um
7:57
Eagle Eagle has done here as well we
7:59
done with xx1 and x01 Eagle deraa um
8:02
drivetrain on access is we've we've
8:06
moved the deraa slightly a little bit
8:08
further round this position here so
8:09
there's more chain wrap which gives a
8:11
more longevity uh of the drivetrain
8:13
itself it's more teeth engaged with the
8:15
chain um and also the Dera cage itself
8:18
is actually a little bit higher it's
8:19
about 10 mm higher than our mechanical
8:21
Eagle offering so there's a little bit
8:24
more clearance as well okay so if you're
8:26
you're you're an Enduro racer and you
8:28
hit a mive something here you're going
8:32
to it's going to pop straight back into
8:34
position and then you're going to carry
8:36
on pedaling and it's going to be exactly
8:37
indexed where it should be there's no
8:39
stopping and faffing and fiddling around
8:42
yeah that's the exact function it's not
8:44
necessarily for everyone you don't need
8:46
to replace your mechanical drivetrain
8:48
with an eagle access drivetrain x01 or
8:50
xx1 but you are getting a better
8:53
performing more intuitive more higher
8:57
higher grade product because this is
8:59
ultimately the you know the Pinnacle of
9:01
what we can build well a lot of what we
9:03
buy as bikes though we buy it because we
9:04
want it we don't need it you know we buy
9:07
it because we want it well we talked
9:09
quite a lot about the drive Trend let's
9:11
get the bike down and have a little look
9:13
at the dropper post the other cool thing
9:15
about access and getting rid of all that
9:16
cables and hoses and and kind of
9:21
uh yeah you have two hoses now you've
9:23
got a a brake hose and a brake hose and
9:26
the rest of it's all done electronically
9:28
wirelessly so
9:29
um yeah Eagle controller on this side
9:31
and Reverb control on this side and yeah
9:34
that button if you can just about
9:37
hear is actuating the the um the motor
9:41
and the gearbox inside the seat post
9:43
here which is allowing you to drop it
9:44
now this is as it works on radio
9:47
frequency Bluetooth and plus it is as
9:50
close to instantaneous as can possibly
9:52
be yes I notic it was when I rode it
9:54
around the car par there's no delay on
9:55
it at all you're not going to press a
9:56
button and go should I go yeah okay it's
9:59
it's instantaneous you press that button
10:01
and that post drops down Y and it's very
10:03
Spanky on the way up go on yeah so you
10:06
can sit on it and drop it a couple of
10:08
centimeters a few centimeters wherever
10:09
you want to do um you know if you if you
10:12
tap that button really fast you can
10:14
bring it up halfway you can bring it all
10:16
the way to the top yeah yeah so I I'm
10:18
one of those riders that actually does
10:20
put my sadle down just an inch here and
10:22
just an inch there quite a lot like a
10:24
bit of tech climbing yeah yeah I use it
10:26
a lot for that and just riding around
10:28
the car park here um I noticed that it
10:31
it's actually a lot easier to to get
10:33
that little adjustment than I found it
10:35
with with other dropper posts so yes if
10:37
you're a fan of that Reverb itself there
10:41
are some key developments here this is
10:42
this is a new and improved and better
10:44
Reverb all around um but the body of the
10:47
Reverb in in a lot of ways is similar to
10:49
current Reverb stealth pretty much from
10:52
pretty much from the head down to about
10:54
this point here the internals are very
10:56
similar they developed we've got new
10:57
seals we've got where where using a new
11:00
ifp that's quieter that's smoother um
11:03
new oils and seals and build build um
11:06
manufacturing process that's made it
11:07
even more reliable um but the the new
11:10
kind of bit on there as well is this
11:12
part this head unit of it itself is the
11:14
battery the gearbox and the motor that's
11:17
actuating that opening the opening the
11:18
valve basically to allow the Reverb to
11:20
move um and what's really neat about
11:23
this as well is that there's a new
11:24
technology in Reverb access called vent
11:27
valve if you get air in a place where
11:31
it's just meant to be oil you can get a
11:32
little bit of Squish squishy yeah and if
11:34
you get a little bit of Squish to get
11:35
rid of that what we do what we now do is
11:38
you take the post out you have a little
11:39
tool you plug it into the bottom you
11:40
compress the post and it purges the air
11:42
out and you get rid of that squish
11:43
straight away like a a bleed valve
11:45
effectively bu exact vent valve we call
11:47
it yeah you know we really believe that
11:49
this this drivetrain it stands alone in
11:51
terms of technology and performance you
11:53
know there's nothing out there right now
11:54
that that is comparable even to fully
11:58
electronic Wireless Drive trains for
11:59
mountain bikes somebody is going to want
12:01
it probably quite a few people are going
12:03
to want it we hope
12:05
so cool so uh this is launch today it
12:09
will be available soon as uh the Reverb
12:12
and then also as a complete group set
12:14
won't it you uh you can't buy just the
12:17
derailer yet that will come in in due
12:20
course so if you want this now you have
12:22
to go and buy the whole thing well yeah
12:24
in all it in all its rainbow Glory yeah
12:27
right thanks very much for joining us
12:28
Alex and hop on over to single TRW
12:30
world.com if you want more information
12:33
on on this new access access yes Ram
12:38
access Ram Rock shocks access yeah cool
12:40
thanks for joining us
#Sports
