Although Santa Cruz engineered the new Blur 3 as a lightweight full suspension XC race bike, the frame will actually accommodate up to a 120mm travel fork.
We got in a standalone Blur CC frameset and custom built it with a Fox 34 Step-Cast fork, chunky 2.3in tyres and a 150mm travel dropper post.
So, how did the Blur handle the bigger fork and burlier build kit?
Read the full review here to find out! https://singletrackworld.com/2018/12/review-120mm-fork-santa-cruz-blur-pocket-rocket-trail-bike
Show More Show Less View Video Transcript
0:00
[Music]
0:04
everyone it's real here from single
0:06
track magazine and single track WorldCom
0:08
and today I want to chat to you about a
0:10
bike that I've been testing for the past
0:11
few months now firstly we're gonna chat
0:24
a little bit about what that bike is and
0:26
what makes it special then we're going
0:28
to go into some detail about the build
0:30
kit that I've got set up on the test
0:31
bike here and finally and most
0:33
importantly I'm going to tell you how it
0:36
rides on the trail
0:39
[Music]
0:44
[Music]
0:50
right so the bike next to me is of
0:53
course the Santa Cruz blur there many of
0:55
you will be familiar with the blur name
0:57
it is a bike that's been in Santa Cruz
0:58
lineup in the past this new model those
1:01
shares very little in common with those
1:03
previous models in terms of the broader
1:05
Santa Cruz lineup it slots right in
1:07
between highball hardtail and the tall
1:10
boys short travel trail bike the blur
1:12
has a little less travel than the
1:14
tallboy we've got 100 millimeters of
1:15
travel here courtesy of the VPP
1:17
suspension design it's rolling on 29
1:20
inch wheels and 29 inch wheels only you
1:23
cannot fit plus tires on this bike and
1:25
it's all built around a lightweight
1:27
high-tech carbon fiber frame which santa
1:30
cruz states is the lightest front
1:31
suspension frame it has ever produced
1:33
now earlier this year I traveled to
1:35
California to test out the new blur on
1:37
some of the trails local to Santa Cruz
1:39
headquarters the bike that I tested was
1:41
set up as a flat-out cross-country race
1:43
bike so it had 100 millimeter travel Fox
1:46
32 step pass Forks and very lightweight
1:48
maxis Aspen race tires now I got along
1:51
with the bike really well I thought it
1:53
was a load of fun but it was really
1:54
efficient and very direct to ride but
1:57
for my intermediate riding level I did
1:58
find that the 20 fork and the farce
2:00
rolling tires were holding back the bike
2:02
a little bit in the rough stuff now
2:04
Santa Cruz do offer the blur in several
2:06
complete bike options but they also
2:08
offer it as a standalone frame set we've
2:10
got the blur CC frame set here and we've
2:13
built it up from scratch as a long-term
2:15
test bike for those of you wondering the
2:17
medium frame set I've got here came in
2:19
at 2.25 kilograms and that's including
2:21
the rear shop the rear axle c-collar and
2:24
associated hardware so it is quite
2:26
lightweight but it's not quite as light
2:28
as something like a Scotts Park RC or a
2:30
canyon luxe SLX still impressive though
2:33
for a carbon fiber Julie that is using a
2:35
multi pivot suspension design
2:37
now although santa cruz has targeted the
2:39
blur a cross-country racing the frame
2:42
will actually accommodate up to a 120
2:44
millimeter travel fork and that's
2:46
exactly what we've done here i've
2:48
plugged in a fox 34 step cast fork which
2:51
has 120 millimeters of travel 34
2:53
millimeter diameter stanchions
2:55
but it's also got a very impressive
2:56
weight it's just sixteen hundred and
2:58
fifty
2:59
it's a fantastic option for this kind of
3:01
new-school aggressive cross-country bike
3:03
so think get ESB 100 intense sniper and
3:07
the Santa Cruz blur now with that longer
3:09
fork on the front the geometry does
3:10
change everything lifts up a little bit
3:13
and the angles do slacken out of it so
3:15
the head angle kicks back to sixty eight
3:17
point one degrees the seat angle relaxes
3:19
to seventy-three point one degrees and
3:21
the bottom bracket lifts up by about 12
3:24
millimeters measured here statically to
3:26
the floor it measures at three hundred
3:28
and forty millimeters to match the
3:30
longer travel fork and the slacker
3:31
geometry are built up the blur with a
3:33
slightly burly apart spec - we've got
3:36
wheels from santa cruz these are the
3:38
reserved carbon 27 rims they have a 27
3:41
millimeter internal rim width and
3:43
they're set up to bliss with Bontrager
3:45
XR 5 team issue tires these are listed
3:48
at 2.3 inches wide and actually measure
3:50
up a touch wider than that they have
3:52
quite an aggressive tread pattern and
3:54
I've been able to run those anywhere
3:56
between 18 to 25 psi depending on the
3:59
trail conditions the cockpit comes from
4:01
rental we've got 760 millimeter wide
4:03
rental carbon fat bars and that's paired
4:06
to a 50 millimeter apex stem I've also
4:09
got a GaN GE one Evo grips here I really
4:12
like the feel of these grips and they're
4:14
flared ends actually widens the
4:16
effective bar with little as well so it
4:18
gives it quite a trail bike feel on the
4:20
front of the blur the other crucial
4:22
component that I wanted to fit to this
4:23
bike was a dropper post now Santa Cruz
4:26
has built the blur frame with a 31-point
4:28
six millimeter diameter seat tube it's
4:30
quite compact as well and there's plenty
4:32
of stand over clearance and that allows
4:34
a load of flexibility to fit a
4:35
reasonably long dropper post in my case
4:38
I've got a 150 millimetre travel race
4:40
face turbine R this is structurally
4:43
identical to a Fox transfer dropper post
4:45
so as a result it works really well it's
4:48
been rock solid throughout testing and
4:50
it's got a really nice fast return speed
4:52
with an audible top out clunk so you
4:54
always know when it's at full height I
4:56
am running the race based turbine
4:58
dropper post lever and I must say it is
5:00
much nicer to use than the Fox transfer
5:02
remote the rest of the build kit comes
5:04
from SRAM we've got an XO one Eagle
5:06
drivetrain on here and level ultimate
5:09
brakes which are absolute
5:10
superb as its set up here without pedals
5:12
this bike weighs in at 11.6 4 kilos so
5:16
pretty poor key for a cross-country bike
5:18
and definitely heavier than the blur
5:19
that I tested back in California right
5:22
so I guess you're wondering how does
5:23
this bike ride and I will admit
5:25
initially I was somewhat skeptical
5:27
because not every cross-country bike
5:28
takes well to having a longer travel
5:30
fork plugged in the front of it in the
5:32
case of the blur though this fox 34 does
5:35
wonders to this bike it is a much
5:37
stiffer fork torsionally than say Fox 32
5:40
and especially compared to a Fox 32 step
5:43
cast now the blur frame is already quite
5:45
stiff and stout it's built with
5:48
oversized carbon fiber tubes and we've
5:50
got alloy linkages and angular contact
5:51
bearings which minimize the amount of
5:54
wiggle and flex through the back end
5:56
speaking of Santa Cruz has built this
5:58
frame to be one by specific without any
6:01
need to factor in a front derailleur
6:02
they've been able to beefing up the
6:04
bottom bracket area they've also been
6:06
able to put in this extra vertical
6:08
upright on the drive side as well as the
6:10
non-drive side now aside from giving it
6:13
a really nice symmetrical look it also
6:14
helps to strengthen the rear swingarm
6:16
gives it a load of stiffness all the way
6:19
to the rear axle and as a result the
6:20
blur has a really purposeful really
6:22
precise feeling through tight single
6:24
track even with the perlier build kit
6:27
despite maintains its snappy demeanor
6:29
which has made the blur such a great
6:30
cross-country bike Santa Cruz has built
6:32
the blur with just the right amount of
6:34
anti-squat so when you are mashing on
6:36
the pedals the suspension does stiffen
6:38
up a little bit lifts the whole bike up
6:40
and propels you forward with fantastic
6:42
acceleration but there's not so much
6:44
anti-squat as to stifle the suspension
6:46
deeper into the travel in fact I would
6:48
say that the blur has quite an open and
6:50
active feeling to its suspension it has
6:52
great traction the rear tire follows the
6:54
terrain really well I typically run the
6:56
rear shop in full open because I think
6:58
it pedals well enough as it is but by
7:01
leaving the rear shock full open and
7:02
allows a really nice active feel the
7:04
whole bike is quite comfortable to ride
7:06
especially for 100-millimeter travel
7:08
bike that already pedals quite well the
7:10
big tubeless tires definitely help here
7:12
I'm a big fan of these XR fives and also
7:15
the low pressures you can run them
7:16
at speaking in the rear tire there is
7:18
plenty of clearance in the back end here
7:20
now santa cruz states you can fit up to
7:22
a 2.35 maybe even a 2.4 inch wide tire
7:26
in the back of the blur that's somewhat
7:28
dependent on the width of the rim and
7:29
also the tire model because they do vary
7:31
somewhat but there is still clearance in
7:33
the backend to run some proper tires in
7:35
the back of this bike combined with the
7:37
active suspension this bike climbs
7:38
really really well I was a little
7:40
worried at first that the slacker seat
7:42
angle might put too much of my weight
7:44
behind the bottom bracket but that
7:46
proved to be completely unfounded in
7:47
fact within the first couple of rides
7:49
I actually shifted the saddle a little
7:50
bit further backwards on the rails to
7:52
get my knees in the right spot over the
7:54
pedals since then it's been really
7:55
comfortable and I've had no issues with
7:57
climbing whatsoever the front end does
7:59
take a little bit more waiting on the
8:01
front tire to keep it from wandering on
8:03
steep climbs but it's not as much as
8:05
you'd think because the cockpit is
8:07
already fairly low on this bike with
8:08
that very short integrated head tube one
8:11
other thing I was worried about with the
8:13
bigger fork on this bike was the tall
8:14
bottom bracket hive and whether that
8:16
would affect cornering and handling on
8:18
the trail now that concern proved to be
8:20
completely unfounded mostly because the
8:22
bottom bracket isn't actually that high
8:23
when I'm sitting on the bike and the
8:25
suspension is it sag the Beebe measures
8:28
304 millimeters off the ground still
8:30
there is a little more clearance there
8:32
and I've actually found that really
8:33
beneficial I can't really recall any
8:35
moment where I smack the pedals on a
8:37
rock and that means I've been able to
8:39
ride some pretty technical
8:40
rocky slabby climbs without fear of
8:43
smashing the pedal and stalling on that
8:45
climb particularly with wide open
8:47
corners as well I've been able to keep
8:49
our down more consistently which for a
8:51
lightweight trail bike or cross country
8:52
bike is exactly what you want combined
8:55
with that wider handlebar that short
8:57
stem and that torsionally stiff frame
8:59
this bike corners so well it's really
9:02
rigid really precise particularly when
9:04
you're loading up the pedals through the
9:06
turns and I had no problems with agility
9:08
on this bike whatsoever now on the note
9:11
of handling and front-end steering I've
9:13
actually been doing some offset testing
9:15
on the front of the blur now if you're
9:16
looking at a complete bike Santacruz
9:18
builds the blur frame around a 44
9:20
millimeter offset fork with the Fox 34
9:23
step cast on the front here I've
9:25
actually got one in a 44 millimeter
9:27
offset
9:28
in a 51 millimetre offset - and it does
9:30
change the handling now I've got some
9:33
more back to back testing to be done and
9:34
there will be a full feature coming on
9:36
the offset test on the front of the blur
9:38
so make sure you stay tuned to
9:39
singletrack WorldCom and their YouTube
9:41
and Facebook channels for the full
9:43
feature on that offset test as you can
9:46
probably tell I've had a load of fun
9:48
testing this bike with the 120
9:49
millimeter fork and that burly apart
9:51
spec I think the blur is such a capable
9:54
and versatile bike and you can get a
9:55
whole lot more out of it by just
9:57
changing a few other components in fact
9:59
you could get the one bike with two sets
10:01
of forks and potentially a few pairs of
10:03
tires and change it up depending on the
10:05
writing that you're doing you could have
10:07
this nice fun capable pocket-sized trail
10:10
bike for ninety percent of the time and
10:12
then with the swap - 100 millimeter
10:14
travel for some faster rolling tires
10:16
you've got a cross country race bike so
10:18
there's a load of versatility in this
10:20
chassis to be taken advantage of now if
10:22
you want to read the full in-depth
10:23
feature on my experience with the blur
10:25
setup as it is here then make sure you
10:27
jump on singletrack WorldCom to read the
10:29
full review and if you liked this video
10:31
make sure you subscribe to our YouTube
10:33
channel sign up to our Facebook page
10:35
and we'll have plenty more videos coming
10:37
for you in the near future hope you've
10:39
enjoyed watching and I'll see you guys
10:41
next time
10:41
- room
#Sports
